Hi-Lift Cast Steel Jack
The cast and steel jack is exactly the same as the all-cast jack except that it has four stamped high-strength steel parts. We stamp and form the parts in-house; that allows us to offer the jack at a lower price, yet we still maintain the rigid quality standards that every Hi-Lift product must meet.




  • Made of Cast & Stamped Steel Parts.
    •

  • 7000lb (3175.14kg) Tested Capacity.
    •

  • Available in 36", 42", 48", & 60" Heights. (91, 107, 122, & 152cm)
    •

  • Lifts, Winches, Clamps, & More.
    •

  • Tested and certified to meet applicable requirements of ASME B30.1-2015.
    •

Hi-Lift Cast Steel Jack

£105.00Price
Sales Tax Included |
Quantity

  • Size: 36” (91 cm)
    Min. Lift Height: 4.5" (11.43 cm)
    Max. Lift Height: 27" (68.58 cm)
    Overall Height: 41" (104.14 cm)
    Width: 5" (12.7 cm)
    Depth: 9.63" (24.46 cm)
    Rated Load (RL): 4,660 lbs (2,113 kg)
    RL on upper 12" (30.5cm): -
    Tested Load (TL): 7,000 lbs (3,175 kg)
    TL on upper 12" (30.5cm): -
    Winching Capacity: 5,000 lbs (2,268 kg)
    Clamping Capacity: 750 lbs (340 kg)
    Weight: 25 lbs (11.35 kg)



    Size: 42” (107 cm)
    Min. Lift Height: 4.5" (11.43 cm)
    Max. Lift Height: 32" (81.28 cm)
    Overall Height: 43.5" (110.49 cm)
    Width: 5" (12.7 cm)
    Depth: 9.63" (24.46 cm)
    Rated Load (RL): 4,660 lbs (2,113 kg)
    RL on upper 12" (30.5cm): -
    Tested Load (TL): 7,000 lbs (3,175 kg)
    TL on upper 12" (30.5cm): -
    Winching Capacity: 5,000 lbs (2,268 kg)
    Clamping Capacity: 750 lbs (340 kg)
    Weight: 26.35 lbs (11.95 kg)



    Size: 48” (122 cm)
    Min. Lift Height: 4.5" (11.43 cm)
    Max. Lift Height: 37.24" (94.59 cm)
    Overall Height: 48.75" (123.83 cm)
    Width: 5" (12.7 cm)
    Depth: 9.63" (24.46 cm)
    Rated Load (RL): 4,660 lbs (2,113 kg)
    RL on upper 12" (30.5cm): -
    Tested Load (TL): 7,000 lbs (3,175 kg)
    TL on upper 12" (30.5cm): -
    Winching Capacity: 5,000 lbs (2,268 kg)
    Clamping Capacity: 750 lbs (340 kg)
    Weight: 27.66 lbs (12.55 kg)


    Size: 60” (122 cm)
    Min. Lift Height: 4.5" (11.43 cm)
    Max. Lift Height: 48.25" (123.83 cm)
    Overall Height: 59.25" (150.5 cm)
    Width: 5" (12.7 cm)
    Depth: 9.63" (24.46 cm)
    Rated Load (RL): 4,660 lbs (2,113 kg)
    RL on upper 12" (30.5cm): 2,660 lbs (1206 kg)
    Tested Load (TL): 7,000 lbs (3,175 kg)
    TL on upper 12" (30.5cm): 4,000 lbs (1,814 kg)
    Winching Capacity: 5,000 lbs (2,268 kg)
    Clamping Capacity: 750 lbs (340 kg)
    Weight: 30.12 lbs (13.66 kg)
